DirectFit™ Black Vinyl Suspension Seat for Toyota Forklift

Part Number
E-53710-23620-71
$539.99
In stock
  • Package Quantity: 1
  • Replaces Toyota no(s): 53710-23620-71
  • Includes Seat Belt , Operator Presence Switch, Folding Backrest, Integrated Document Box, Adjustable Slide Tracks & Wrap Around Backrest Cushion
  • Weight Adjustment: 92lbs to 265lbs
  • Suspension Height: 4.000"
  • Suspension Stroke: 1.575"
  • Mounting Pattern: 9.000", 11.000" Or 13.000" Width X 10.000" Or 11.000" Front to Back
  • Bottom Cushion Width: 22.638"
  • Backrest Cushion Width: 20.276"
  • Seat Depth: 21.654"
  • Seat Height W/Suspension: 24.213"
  • Universal Mounting Design
  • Compatible With Toyota Forklift(s): 02-7FD10, 02-7FD15, 02-7FD18, 02-7FD20, 02-7FD25, 02-7FD30, 02-7FDJ35, 02-7FDK20, 02-7FDK25, 02-7FDK30, 02-7FG10, 02-7FG15, 02-7FG20, 02-7FG25, 02-7FG30, 02-7FGJ35, 02-7FGK20, 02-7FGK25, 02-7FGK30, 40-7FG15, 40-7FG20, 40-7FG23, 40-7FG25, 40-7FGK20, 40-7FGK25, 42-7FG15, 42-7FG18, 42-7FG20, 42-7FG25, 42-7FGK20, 42-7FGK25, 60-7FD20, 60-7FD25, 60-7FD30, 62-7FD20, 62-7FD25, 62-7FD30, 7FD10, 7FD15, 7FD20, 7FD25, 7FD30, 7FDJ35, 7FDK20, 7FDK25, 7FDK30, 7FG10, 7FG15, 7FG20, 7FG25, 7FG30, 7FGJ35, 7FGK20, 7FGK25, 7FGK30, 02-7FD35, 02-7FD40, 02-7FD45, 02-7FDA50, 02-7FDK40, 02-7FG35, 02-7FG40, 02-7FG45, 02-7FGA50, 02-7FGK40, 42-7FD35, 42-7FD40, 42-7FD45, 42-7FDA50, 42-7FDK40, 7FD35, 7FD40, 7FD45, 7FDK40, 7FG35, 7FG40, 7FG45, 7FGK40, 02-7FDN15, 02-7FDN20, 02-7FDN25, 02-7FDN30, 02-7FGN30, 40-7FGN15, 40-7FGN20, 40-7FGN25, 42-7FGN15, 42-7FGN20, 42-7FGN25, 60-7FDN20, 60-7FDN25, 60-7FDN30, 62-7FDN20, 62-7FDN25, 62-7FDN30, 7FDN15, 7FDN20, 7FDN25, 7FDN30, 7FGN30, 3FD100, 3FD115, 3FD135, 3FDE150, 3FDE160, 40-7FB15, 40-7FB20, 40-7FB25, 7FB10, 7FB14, 7FB15, 7FB18, 7FB20, 7FB25, 7FB30, 7FBH10, 7FBH14, 7FBH15, 7FBH18, 7FBH20, 7FBH25, 7FBJ35, 50-5FD60, 50-5FD70, 5FD50, 5FD60, 5FD70, 5FD80, 5FDM60, 5FDM70, 5FG50, 5FG60, 5FG70, 60-5FD80, 7FBE10, 7FBE13, 7FBE15, 7FBE18, 7FBE20, 7FDAU50, 7FDKU40, 7FDU35, 7FDU45, 7FDU60, 7FDU70, 7FDU80, 7FGAU50, 7FGCU35, 7FGCU45, 7FGCU55, 7FGCU60, 7FGCU70, 7FGKU40, 7FGU35, 7FGU45, 7FGU60, 7FGU70, 7FGU80, 7FDU15, 7FDU18, 7FDU20, 7FDU25, 7FDU32, 7FDU30, FB50, FB60, 7FGCU20, 7FGCU25, 7FGCU30, 7FGCU32, 7FGU15, 7FGU18, 7FGU20, 7FGU25, 7FGU30, 7FGU32
More Information
Part NumberE-53710-23620-71
Model02-7FD10, 02-7FD15, 02-7FD18, 02-7FD20, 02-7FD25, 02-7FD30, 02-7FD35, 02-7FD40, 02-7FD45, 02-7FDA50, 02-7FDJ35, 02-7FDK20, 02-7FDK25, 02-7FDK30, 02-7FDK40, 02-7FDN15, 02-7FDN20, 02-7FDN25, 02-7FDN30, 02-7FG10, 02-7FG15, 02-7FG20, 02-7FG25, 02-7FG30, 02-7FG35, 02-7FG40, 02-7FG45, 02-7FGA50, 02-7FGJ35, 02-7FGK20, 02-7FGK25, 02-7FGK30, 02-7FGK40, 02-7FGN30, 3FD100, 3FD115, 3FD135, 3FDE150, 3FDE160, 40-7FB15, 40-7FB20, 40-7FB25, 40-7FG15, 40-7FG20, 40-7FG23, 40-7FG25, 40-7FGK20, 40-7FGK25, 40-7FGN15, 40-7FGN20, 40-7FGN25, 42-7FD35, 42-7FD40, 42-7FD45, 42-7FDA50, 42-7FDK40, 42-7FG15, 42-7FG18, 42-7FG20, 42-7FG25, 42-7FGK20, 42-7FGK25, 42-7FGN15, 42-7FGN20, 42-7FGN25, 50-5FD60, 50-5FD70, 5FD50, 5FD60, 5FD70, 5FD80, 5FDM60, 5FDM70, 5FG50, 5FG60, 5FG70, 60-5FD80, 60-7FD20, 60-7FD25, 60-7FD30, 60-7FDN20, 60-7FDN25, 60-7FDN30, 62-7FD20, 62-7FD25, 62-7FD30, 62-7FDN20, 62-7FDN25, 62-7FDN30, 7FB10, 7FB14, 7FB15, 7FB18, 7FB20, 7FB25, 7FB30, 7FBE10, 7FBE13, 7FBE15, 7FBE18, 7FBE20, 7FBH10, 7FBH14, 7FBH15, 7FBH18, 7FBH20, 7FBH25, 7FBJ35, 7FD10, 7FD15, 7FD20, 7FD25, 7FD30, 7FD35, 7FD40, 7FD45, 7FDAU50, 7FDJ35, 7FDK20, 7FDK25, 7FDK30, 7FDK40, 7FDKU40, 7FDN15, 7FDN20, 7FDN25, 7FDN30, 7FDU15, 7FDU18, 7FDU20, 7FDU25, 7FDU30, 7FDU32, 7FDU35, 7FDU45, 7FDU60, 7FDU70, 7FDU80, 7FG10, 7FG15, 7FG20, 7FG25, 7FG30, 7FG35, 7FG40, 7FG45, 7FGAU50, 7FGCU20, 7FGCU25, 7FGCU30, 7FGCU32, 7FGCU35, 7FGCU45, 7FGCU55, 7FGCU60, 7FGCU70, 7FGJ35, 7FGK20, 7FGK25, 7FGK30, 7FGK40, 7FGKU40, 7FGN30, 7FGU15, 7FGU18, 7FGU20, 7FGU25, 7FGU30, 7FGU32, 7FGU35, 7FGU45, 7FGU60, 7FGU70, 7FGU80, FB50, FB60
